Luckypro 1hp Self-Priming Cast Surface Water Pump

Sold by Mr. Amos · Accra Metropolitan

Technical Specifications Motor Power: 1.0 HP (0.75 kW) Voltage / Frequency: 220V–240V / 50Hz (Single-Phase) Winding: 100% copper wire motor winding Maximum Flow Rate (Q_{max}): 50–60 L/min (3.0–3.6 m3/h) Maximum Head (H_{max}): 40–50 meters Maximum Suction Lift: up to 8–9 meters Inlet / Outlet Port Size: 1" × 1" (25 mm) female thread Construction Materials & Design Pump Body: heavy-duty cast iron casing Impeller: precision brass impeller Diffuser & Venturi Tube: high-strength techno-polymer (Noryl) Motor Casing: aluminum housing for heat dissipation Shaft: chrome-plated / stainless steel shaft Mechanical Seal: ceramic / graphite Protection Rating: IP44 with built-in thermal overload protector
